Passenger Lift

Passenger Lift Specification

Door Opening Size
Automatic Touch Sense Smart Doors

Inclination
Eco Mode (Saves up to 80% Power)

Power Supply
3-Phase

Speed
1.0 m/s sq m/hr

Working Temperature
Cross Flow Fan with Auto ON-OFF Timer Kelvin (K)

Capacity
500 to 2000 Kgs Ton

Passenger Lift Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
All India

About Passenger Lift

Product details:

Quality	European Standard MRL Elevator
Certified	CEIG approved, ISO 9001 - 2015 Certified
Materials	AISI 304 Stainless Steel
Finishes	Elegant Hairline Finish
Mechanism	Advanced Traction System
Controller	Advanced Reprogrammable Controller
Safety Features	Asian Rescue Device (ARD), Automatic Fault Rectifier (AFR), Auto Tuning Device (ATD), Child Safety- touch sense smart doors, Passenger & Cabin Safety, CAN BUS Communication, 5-Way criss-cross beams Infrared Screen sensor (254 beams), Encoder Unit.

Product Specifications:

Capacity	500 to 2000 Kgs
Speed	1.0 m/s
Travel Height	Up to 20 meters (customizable)
Drive Type	Gearless Traction Motor (Energy Efficient)
Power Supply	3-Phase
Energy Efficiency	Eco Mode (Saves up to 80% Power)
Door Type	Automatic Touch Sense Smart Doors
Flooring Options	Anti-Skid PVC Vinyl / Granite Fixing Provision
Ventilation	Cross Flow Fan with Auto ON-OFF Timer
Lighting	LED Direct & Indirect Lighting with Auto ON-OFF
Control System	Full Collective Control System
Emergency Features	Emergency Light, Emergency Siren, Battery Backup
Display & Indicators	Seven-Segment Digital Display with Floor Annunciator & Arrival Gong
Safety Sensors	5-Way criss-cross Infrared Beams (254 Beams)
Access Control	Privacy Lock, Key Switch Access for Restricted Floors
Brake System	Dynamic Disk Brake (110V DC) with Brake Monitor
Installation Type	Machine Room Less (MRL) / Machine Room Type (Customizable)
Warranty & Maintenance	5 Years Warranty + 5 Years Free Maintenance

Built for performance, safety, and reliability, our Commercial Lifts are engineered to handle the heavy-duty demands of modern infrastructure. Whether you need Passenger Lifts for offices and malls, Hospital Lifts for stretcher-friendly mobility, Goods Lifts for industrial usage, Car Lifts for parking towers, or Dumb Elevators for restaurants and hotels Asian Lifts delivers unmatched value and excellence.

Why Choose Our Commercial Elevators?

Heavy-Duty Build - Crafted with high-grade stainless steel and robust engineering for long life.
Precision & Safety - Equipped with advanced safety mechanisms, rescue operations, and child-safety features.
Smart & Scalable -Fully programmable control systems, IoT integration, and modular designs for expansion.
Design Flexibility - Choose from glass panels, custom cabin interiors, powder-coated finishes, and designer doors.
Eco-Efficient - Energy-saving systems like Eco Mode and gearless drives reduce operating costs.

From corporate buildings and educational institutions to healthcare, retail, and logistics zones, our elevators are CEIG approved, ISO 9001:2015 certified, and built to European standards ensuring safety, durability, and high performance.

Handover Process -Engineered to Precision

We ensure that every commercial lift is installed, tested, and delivered with seamless documentation and operational assurance. Each lift is calibrated for peak performance and handed over only after comprehensive training and checks.

Included in the Handover:
